- Semi-dry blotting for transferring of proteins from 4 mini gels (Western Blotting)
Improved Electrode plate setting enabled;
uniform and firm contact of gels and membranes; fast blotting
- Electrode plate size: 205×200 mm
For use in 4 mini gels (8 x 9cm), or Larger size gel blotting available - Rapid semi-dry blotting is possible with AE-1465 EzFastBlot (10-30min)
- Blotting high molecular protein is possible with WSE-7210 EzFastBlot HMW (30-60min)
- Expert roller included for easy setting layout (gel, membrane, filter paper)
- 1/10 of transfer buffer enough of a wet blot
- Electrode for drug resistance: washable system
Specifications
WSE-4045 HorizeBLOT 4M | |
---|---|
Application | Western blotting |
Electrode size | 205 (W) x 200 (D) mm |
Distance between electrodes | Min: 3 mm, Max: 15 mm |
Available number of gel for blotting | 4 mini gels |
Method | Vertical (Semi-dry blotting) |
Blotting solution volume | 100-400 mL (depending on the size and number of gel) |
Electrode polarity | Top: Cathode / Bottom: Anode |
Material | Main unit: Acrylic Anode: Platinized titanium Cathode: Corrosion-resistant stainless steel |
Safety measure | Power lead wire with safety terminal, reverse polarity prevention |
Dimension / Weight | 246 (W) x 235 (D) x 92 (H) mm (Main unit without projection) 3.0 kg (except wiring) |
Components | WSE-4045 main unit 1 ea Power lead wire with safety terminal and reverse polarity prevention 1 ea Roller 1 ea |
Ordering Information
Code No. | Description | Unit |
---|---|---|
0245-2322476 | WSE-4045 HorizeBLOT 4M | 1 set |
0245-2322479 | Blotting roller | 1 ea |
0245-2322462 | Safety leads | 1 ea |
