Features
e-PAGEL HR is a higher-grade product of e-PAGEL.
High-speed migration is possible; the shortest migration time is 20 min.
Sharp bands (especially, separation ability in low molecule domain improves)
Expiration date of use: 1 year
Minimizing smiling
Hardly deform-able gradient gel
Stable quality, High reproducibility
Glass plates with good thermal stability
Easy to set on the apparatus and take off the gel from the glass plate
Varieties of gels are available, including a wide range of gel percentages and wells
Compatible electrophoresis apparatus: ATTO Mini Gel Size Electrophoresis System (WSE-1150P PageRunAce, WSE-1165 Mini-Slab)
※This gel cast includes plates whose total thickness is 5 mm, so Plate holders for PAGEL are required.
* Gels do NOT contain SDS. Electrophoresis with a buffer solution containing 24mM Tris + 192mM Glycine + 0.1% SDS (AE-1410 EzRun) is Laemmli method, and one without SDS (WSE-7055 EzRun TG) is Ornstein-Davis method.
* We recommend buffer [WSE-7065 EzRunMOPS] for high-speed migration.
* Use buffer solution containing 25mM Tris and 192mM Glycine or our product, [WSE-7055 EzRunTG] for DNA electrophoresis.
* The way of making [e-PAGEL HR] is different from that of [e-PAGEL] so the migration pattern may not be the same.
| Specification | EHR-TXL e-PAGEL HR (14-wells) | EHR-RXL e-PAGEL HR 18-wells |
|---|---|---|
| Usage | Polyacrylamide gel electrophoresis of protein or nucleic acid (SDS-PAGE, native PAGE etc) | Polyacrylamide gel electrophoresis of protein or nucleic acid (SDS-PAGE, native PAGE etc) |
| Storage | 1 year when stored in a refrigerator (NOT to be frozen) | 1 year when stored in a refrigerator (NOT to be frozen) |
| sample loading volume | maximum 24 μL/well | maximum 15 μL/well |
| Package | 10 plates/box | 10 plates/box |
| Glass plate size | 120 (W) x 100 (H) mm | 120 (W) x 100 (H) mm |
| Gel/buffer composition | Polyacrylamide, Tris-HCl buffer | Polyacrylamide, Tris-HCl buffer |
| Gel size | 90 (W) x 83 (H) mm, thickness 1 mm | 90 (W) x 83 (H) mm, thickness 1 mm |
| Code No. | Description | Unit |
|---|---|---|
| 0245-2331970 | EHR-T520L e-PAGEL HR 5~20% 14-well 10 gels | 1pk |
| 0245-2331975 | EHR-T1020L e-PAGEL HR 10~20% 14-well 10 gels | 1pk |
| 0245-2331950 | EHR-T7.5L e-PAGEL HR 7.5% 14-well 10 gels | 1pk |
| 0245-2331955 | EHR-T10L e-PAGEL HR 10% 14-well 10 gels | 1pk |
| 0245-2331960 | EHR-T12.5L e-PAGEL HR 12.5% 14-well 10 gels | 1pk |
| 0245-2331965 | EHR-T15L e-PAGEL HR 15% 14-well 10 gels | 1pk |
| 0245-2332070 | EHR-R520L e-PAGEL HR 5~20% 18-well 10 gels | 1pk |
| 0245-2332075 | EHR-R1020L e-PAGEL HR 10~20% 18-well 10 gels | 1pk |
| 0245-2332050 | EHR-R7.5L e-PAGEL HR 7.5% 18-well 10 gels | 1pk |
| 0245-2332055 | EHR-R10L e-PAGEL HR 10% 18-well 10 gels | 1pk |
| 0245-2332060 | EHR-R12.5L e-PAGEL HR 12.5% 18-well 10 gels | 1pk |
| 0245-2332065 | EHR-R15L e-PAGEL HR 15% 18-well 10 gels | 1pk |
